Hacking Canon MegaTank and clearing 5B00 Lock: A Native, Key-Free Waste-Ink Reset over USB with Ghidra, Frida and friends

Introduction

Everything here is implemented in the open-source canon-megatank-reset (zlib code; CC-BY-4.0 docs available in mkdocs here).

Note, I am finalizing a proper paper I hope to present later this year on this misadventure

If you own a Canon MegaTank — a G6020, G6050, G7020, or any of the G5000/G6000/G7000-generation refillable-tank printers — there is a fair chance you will one day power it on and find it dead, stricken with error 5B00.

5B00 is not a hardware failure; it is a counter in EEPROM crossing a threshold, and firmware refusing to print until that counter is reset — a service-mode operation Canon’s field tools perform and the consumer firmware hides. On this printer generation, the classic in-firmware reset combo was removed: the printer enters service mode but accepts and ignores the clear.

So we did it the other way: figure out what the maintenance lock actually is, recover the protocol, and clear it ourselves — on Linux, over libusb, with no vendor cloud, no Windows, and no per-unit key. This post ideally serves as a fairly complete technical reference for that work. It covers the service-mode USB device, the usbprint vendor-control transport, the four-step reset session and the per-session keyword-bound write cipher.

I corroborated findings against WICReset’s binary payload (sorry mate, couldn’t help myself to some friendly decompilation).

When You Need This

• Your G-series MegaTank is stuck on 5B00 (“ink absorber full” / “support code 5B00”)
• You have installed (or are installing) a fresh waste-ink absorber kit
• You want an offline, key-free, fleet-reproducible reset rather than a per-unit cloud license
• You are comfortable entering service mode and issuing USB control transfers as root on Linux

Prerequisites

• Linux with libusb/pyusb
• Root or membership in a group your udev rule grants 04a9 device access
• A G-series MegaTank in service mode (see below) — it enumerates as a different USB device

---

The Lock: Two Devices, One Printer

A MegaTank presents two completely different USB identities depending on mode:

Mode	USB ID	Interfaces	The maintenance lane
Normal	04a9:1865	6 (print, scan, usbscan iface 4, …)	iface 4, bulk 0x03/0x86
Service	04a9:12fe	1 printer-class iface (EP 0x01 OUT / 0x82 IN)	vendor control transfers

Service mode is entered with the Canon button dance: power off, hold ON, tap Stop/Resume five times, release. The LCD goes to a flat block-color field and the printer re-enumerates as 04a9:12fe. That 12fe device is where the waste-counter reset lives — and it speaks a protocol that does not look like the normal-mode usbscan lane at all.

---

usbprint and cracking open Canon’s tooling

AFAICT, on Windows Canon’s tooling talks to the printer through usbprint.sys, and its IOCTL frames map onto USB control transfers. Decompiling usbprint.sys and correlating it against a usbmon capture of the genuine tool pinned the exact mapping:

Direction	bmRequestType	bRequest	wValue	data stage
VENDOR_SET (write)	0x41 (OUT, vendor, interface)	frame byte 0 (the command)	(frame[1] << 8) \| frame[2]	the entire frame, verbatim
VENDOR_GET (read)	0xC1 (IN, vendor, interface)	the command byte	—	response bytes

So a maintenance “frame” like 81 00 00 03 becomes a control-OUT with bRequest=0x81, wValue=0x0000, carrying 81 00 00 03 as its data stage. The reply to a read command comes back on the control-IN pipe (0xC1), never on bulk-IN. Once we moved reads from bulk 0x82 to control-IN 0xC1, the device started answering.

---

The reset is a short, ordered, keyed session. Three frames go out, one value comes back, and the whole thing commits on a clean power-off:

1. set_session — send 81 00 00 03 in the clear. The device length-validates the 0x81 command; an enciphered set_session (a longer frame) STALLs. This frame is the only one that stays plaintext.
2. get_keyword — VENDOR_GET(0x82) returns a live, per-session 3-byte keyword. Pad it to four bytes and “bind” it; this value seeds the cipher for the rest of the session, which is why the reset is device-bound and cannot be replayed as a static byte string.
3. set_command — two 23-byte frames, 85 00 00 || payload(20). The first selects the target (operand 10 07 7c); the second is the actual waste:common clear (operand 0d 00 00). The 20-byte payload is enciphered (next section).
4. get_command (0x86) returns empty — and that is correct, not a failure. There is no “finalize” command in this protocol. Do not gate on a 0x86 reply.
5. Commit. Release the host USB handle (exit the process), then perform a clean power-button shutdown. You will hear the printhead park — that mechanical settle is the EEPROM flush. Power back on and 5B00 is gone; the printer re-enumerates as 04a9:1865.

---

The Write Cipher

The reset payload is not sent in the clear, and getting the encoding right was the last missing piece. The genuine set_command is a two-layer construction:

• An inner functor-3 envelope: a deterministic 20-byte structure, 00 12 01 <op> followed by 16 fixed bytes from an MSVC rand() stream seeded at 0x12345678. This is template data — the G6000-series “CANON-SR5” maintenance family uses functor/method 3.
• An outer functor-2 transform with the buffer roles swapped from the obvious reading: the subject is the 20-byte functor-3 envelope, and the seed is the 4-byte bound keyword from step 2. (An earlier pass had subject and seed reversed, which only ever emits 4 bytes and silently fails.)

The wire frame is 85 00 00 || functor2(envelope3(85 00 00 || op), bound_keyword) — 23 bytes total. Validated 23/23 against ground truth captured from the genuine tool: e.g. for the SELECTOR operand 10 07 7c with a known keyword, the encoder reproduces 85 00 00 db bb 00 67 59 a1 b0 1f 84 2f d5 83 04 4a 3a c3 51 d2 b1 ef byte-for-byte. The full keystream tables (command.index, command.codes, the operator-VM command.shift programs) live in the repo’s own SSOT (printers/canon-g6020/maintenance.yaml) — recovered once, then ours; the tool never reads devices.xml or the vendor binary at runtime. This post gives the shape, the repo gives every byte.

Exploiting 0x8c read back

Service mode answers two status reads, 0x84 and 0x8c, both obfuscated with the per-session keyword. To find the waste counter I captured ~550 read-only sessions (open session → read keyword → read both registers; no writes) against the locked G6020, then looked for the register whose decoded plaintext stays constant while the keyword churns.

0x84 Not it, a linear keyword-XOR stream over a fixed 20-byte device descriptor. Decoded, it is byte-identical every session — clearly not the counter.

0x8c changes every single session. What if 0x8c isn’t a new cipher at all, but the printer echoing its own write keystream? I ran our functor2_transform over a 20-byte zero plaintext, keyed by the same bound session keyword the writes use- and it reproduced 0x8c byte-for-byte. 540 sessions in-sample with zero conflicts, then 16 fresh sessions predicted before I read them.

So 0x8c carries no counter. It is a keyed keystream echo over zeros, and its per-session “variation” is just the keyword moving.

This is exploitable.

A register that echoes our write keystream is a pretty damn good way to weasel in. Those ~550 live responses independently confirm the write cipher we ship is byte-exact against the real printer across hundreds of keywords — the strongest validation of the clear path short of re-running the clear hundreds of times. (The real counter is read through the template’s query.normal select path, [10 07 7C][15], not a bare register read.)

---

The Recovery Procedure

# 0. Install a fresh waste-ink pad kit FIRST. The counter is not lying about its job.

# 1. Enter service mode: power off → hold ON → tap Stop/Resume x5 → release.
#    The printer re-enumerates as 04a9:12fe (flat block-color LCD).

# 2. Dry run (default). Reads the live keyword, builds the enciphered frames,
#    prints exactly what it WOULD send — and writes nothing.
canon-megatank reset-native            # dry-run is the default

# 3. Execute, behind the gates (test-unit UUID, EEPROM pre-dump, write budget, lockfile):
canon-megatank reset-native --execute

# 4. Release the handle (the command exits) and POWER-BUTTON the printer off.
#    Listen for the printhead to park — that is the EEPROM flush.

# 5. Power on. 5B00 is gone; the printer comes back as 04a9:1865 and prints.

The tool refuses to write unless the printer’s IPP UUID matches the configured test unit, an EEPROM pre-dump succeeds, the write budget is intact, and a lockfile is held. None of those gates protect Canon; they protect you from running a destructive EEPROM write against the wrong unit.

---

My favorite things, a RE trifecta.

usbmon shows the bytes; Frida shows the application frame before it is enciphered and handed to the driver; Ghidra explains why. Trace, decompile, correlate, repeat — until all three agree on the same story. They eventually did, and the story was reproducible enough to rebuild from scratch.

Correlating payloads by cracking commercial software followed by rubbing your hands together while saying “I’m in” is highly recommended and you should tell all your friends to do it too

---

Security & Right-to-Repair Considerations

• The “lock” is a policy, shipped as firmware. 5B00 is a counter and a threshold, not a broken part. On this printer generation the in-firmware reset was deliberately removed and pushed to paid, cloud-licensed tooling.
• This is interoperability on owned hardware. The native tool resets a waste-ink counter on a printer you own, after you have installed fresh pads. It does not circumvent a content-protection scheme and it does not pirate the commercial tool — it reimplements the protocol.
• Install the pads first and/or buy / build a continuous drain kit. The one genuinely destructive failure mode here is resetting a truly full absorber and spilling ink. Respect the counter’s actual job.
• The device bytes are local. The cloud in the commercial path is a licensing gate, not a signing oracle; the per-model template is bundled and zero-key “encrypted.” Offline reset is therefore computable without a key. Not that I am saying this is sanctioned, but I am saying I did it and it helped speed things along :eyes:

---

References & Credits

• leecher1337/pixma — the Canon firmware-unpack lineage (pixma_decrypt, pixma_unpack), built on the Context Information Security 2016 talk “Hacking Canon PIXMA Printers — Doomed Encryption.” The firmware-decrypt cross-check builds on this work.
• Context IS, “Hacking Canon PIXMA Printers — Doomed Encryption” (2016) — the original public analysis of Canon’s firmware obfuscation; the zero-key pattern rhymes with what APP.BIN from WICReset uses.
• OctoInkjet / Printer Potty — the waste-ink absorber kits that make a reset safe to perform, and public documentation of the MegaTank waste-counter problem.
• Frida, Ghidra, Wireshark/usbmon, pyusb/libusb — the reverse-engineering and reset toolchain.
• canon-megatank-reset — this work: the native tool, the protocol spec, the full RE trail, the diagrams, and the paper. Code is zlib; docs/paper are CC-BY-4.0.

---

Appendix: Quick Reference Card

Service-mode entry

power off → hold ON → tap Stop/Resume x5 → release   (LCD = flat block color, USB = 04a9:12fe)

Control-transfer mapping (usbprint)

VENDOR_SET (write):  bmRequestType=0x41  bRequest=frame[0]  wValue=(frame[1]<<8)|frame[2]  data=whole frame
VENDOR_GET (read):   bmRequestType=0xC1  bRequest=cmd                                       → response bytes

The session

1. set_session   VENDOR_SET 0x81   data = 81 00 00 03            (PLAINTEXT)
2. get_keyword   VENDOR_GET 0x82   → live 3-byte keyword → pad to 4, bind
3. set_command   VENDOR_SET 0x85   data = 85 00 00 || payload(20)   SELECTOR  (op 10 07 7c)
4. set_command   VENDOR_SET 0x85   data = 85 00 00 || payload(20)   CLEAR     (op 0d 00 00)
5. get_command   VENDOR_GET 0x86   → empty (by design; do not gate on it)
6. commit        release USB handle → clean POWER-BUTTON shutdown → power on

Write cipher

inner: envelope3 = 00 12 01 <op> + 16 fixed LCG bytes (MSVC rand, seed 0x12345678)   [functor/method 3]
outer: payload   = functor2(subject = envelope3, seed = bound 4-byte keyword)         [buffer roles swapped]
wire:  85 00 00 || payload(20)   = 23 bytes   (validated 23/23 vs ground truth)

Template recovery with commercial payload sniffing

APP.BIN (PE resource) --3DES-EDE3-CBC, zero key, zero IV--> ZIP --> devices.srs --(same)--> devices.xml
"Canon G6000 Series"  class=canon.printer.std.standard  specs=CANON-SR5
